Product Details

High-security stainless steel European standard mortise lock case available for 38~52mm door thickness.

3-point stainless steel latch construction with an anti-plug latch, prevent people from trying to open the door illegally without authorization.

A reliable and stable lock management system with encrypted key cards only accepts password verification passed key cards.

Product Details

Automatic lock
After door is opened and handle is released, the lock will lock itself automatically.
If reading card but not open the door, the lock will lock itself automatically in 6 seconds.

Door-Closing Remind
If you entered the room but forget to close the door or if the door is not closed completely, there will be “Di-Di” sound from the lock to remind you close it.

Low Battery Alert
If low battery, there will be beeps to remind you to change batteries, and you can open the door for about 100 times before the batteries are dead.

Emergency Unlock
If battery exhausted or PCB defective, you can use mechanical key to open the door for emergency.

Door-Opening Record
The lock will save the latest 255 pieces of door-opening record. You can know who/when/how opened the door.
This record could be of help if theft or other security problem happens.

Do-Not-Disturb Alert
If guest lock the door inside with deadbolt, blue LED light on the lock panel will flash to alert that the guest need privacy time,
and waiter can not open the door.

Real-Time Clock
Clock function of the lock can effectively control the validity of guest card to prevent guest default on room rate.
The key card get invalidated after check-in time expires.

Function of Encoder:
Works with management software to program cards and configure locks.
Manage guest checking-in, checking-out, etc. (Management software is for free.)

Compatible With: Windows 95, Windows 98, Windows ME, Windows 2000, Windows 2003,
Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10.

Two Types For Option: (Same appearance, different chip)
1) With 125KHz frequency chip, work with T5557 card.
2) With 13.6MHz frequency chip, work with Mifare 1K card.

If the key card is used only for opening door, T5557 card system will be enough.
If the key card is for multifunctional purpose instead of just opening a door, such as for consumption system,
parking system, access control system and so on, you need to choose Mifare 1K card system.

Function of cards:
Read card to open door
Insert card into energy saving switch to gain power

Hotel Logo and information can be printed on the card. (Silk Printing)
We can design the artwork for free. You just need to send the logo file to us.
